EC Centrifugal Fans
CFE22590 SERIES
- Size: Ø225 X 90mm
- Impeller: Plastic PP
- Motor: EC Brushless External Rotor Motor
- Insulation: Class B
- Technical Features: Control input 0-10VDC/PWM, Tach output, Locked rotor protection, reverse polarity, Current limited, soft start
- Weight: 1.50kg
- Impeller: Plastic PP
- Motor: EC Brushless External Rotor Motor
- Insulation: Class B
- Technical Features: Control input 0-10VDC/PWM, Tach output, Locked rotor protection, reverse polarity, Current limited, soft start
- Weight: 1.50kg
|
Model Number |
Voltage |
Operating Voltage |
Current |
Power |
Speed |
Air Flow |
Pressure |
Noise |
|
(V) |
(V) |
(A) |
(W) |
(RPM) |
(CFM) |
(mmH2O) |
dB(A) |
|
|
CFE22590V11BHWPB |
115 |
92~138 |
3.2 |
200 |
3300 |
840.8 |
75.5 |
73 |
|
CFE22590V22BHWPB |
230 |
184 ~ 276 |
1.56 |
200 |
3300 |
840.8 |
75.5 |
73 |
