DC Centrifugal Fans
CFD17569 SERIES
- Size: Ø175 x 69mm
- Impeller: Plastic (UL 94V-0)
- Motor: DC Blushless Motor External Rotor
- Operating Temperature: -10°C to + 70°C
- Insulation: Class B
- Connection: Lead Wire
- Bearing: Ball Type
- Weight: 700g
- Impeller: Plastic (UL 94V-0)
- Motor: DC Blushless Motor External Rotor
- Operating Temperature: -10°C to + 70°C
- Insulation: Class B
- Connection: Lead Wire
- Bearing: Ball Type
- Weight: 700g
Download PDF
CFD17569 SERIES (2020)
|
Model Number |
Voltage |
Current |
Power |
Speed |
Air Flow |
Pressure |
Noise |
|
(V) |
(A) |
(W) |
(RPM) |
(CFM) |
(inH2O) |
dB(A) |
|
|
① CFD17569V24BHWGN |
24 |
1.5 |
36.0 |
3300 |
350.0 |
1.56 |
67 |
|
① CFD17569V48BHWGN |
48 |
1.2 |
57.6 |
3300 |
350.0 |
1.56 |
67 |
|
② CFD13391V48BUWGN |
48 |
1.2 |
57.6 |
4200 |
693.0 |
2.48 |
72 |
W: Lead Wires / B: Ball Type
